Inheritance diagram for IEntity:

[legend]

Public Member Functions
proto external EntityID	GetID ()
	Return unique entity ID.

proto external IEntity	GetParent ()
	Returns parent of this entity (entity on upper level of hierarchy).

proto external IEntity	GetRootParent ()
	Returns top-parent of this entity.

proto external IEntity	GetChildren ()
	Returns first child from this level of hierarchy if there is any.

proto external IEntity	GetSibling ()
	Returns next sibling of this entity (next entity on this level of hierarchy).

proto external VObject	GetVObject ()
	Returns visual object set to this Entity. No reference is added.

proto external EntityPrefabData	GetPrefabData ()

proto external EntityComponentPrefabData	FindComponentData (TypeName typeName)

proto external BaseWorld	GetWorld ()

proto external void	SetFixedLOD (int lod)
	Set fixed LOD. Use -1 for non-fixed LOD.

proto external void	GetTransform (out vector mat[])
	Returns world transformation of Entity.

proto external void	GetWorldTransform (out vector mat[])
	See IEntity::GetTransform.

proto external void	GetLocalTransform (out vector mat[])
	See IEntity::GetTransform.

proto external vector	VectorToParent (vector vec)
	Transforms local vector to parent(world) space.

proto external vector	CoordToParent (vector coord)
	Transforms local position to parent(world) space.

proto external vector	VectorToLocal (vector vec)
	Transforms world space vector to local space.

proto external vector	CoordToLocal (vector coord)
	Transforms world space position to local space.

proto external vector	GetYawPitchRoll ()
	Returns orientation of Entity in world space (Yaw, Pitch, Roll).

proto external void	SetYawPitchRoll (vector angles)
	Sets angles for entity (Yaw, Pitch, Roll).

proto external vector	GetWorldTransformAxis (int axis)
	See IEntity::GetTransformAxis.

proto external vector	GetTransformAxis (int axis)
	See IEntity::GetTransformAxis.

proto external vector	GetLocalTransformAxis (int axis)
	See IEntity::GetTransformAxis.

proto external bool	SetLocalTransform (vector mat[4])
	See IEntity::SetTransform. Returns `false`, if there is no change in transformation.

proto external bool	SetWorldTransform (vector mat[4])
	See IEntity::SetTransform. Returns `false`, if there is no change in transformation.

proto external TNodeId	GetPivot ()
	Returns pivot ID from hierarchy component.

proto external bool	SetTransform (vector mat[4])
	Sets entity world transformation.

proto external vector	GetLocalAngles ()
	Same as GetLocalYawPitchRoll(), but returns rotation vector around X, Y and Z axis.

proto external vector	GetLocalYawPitchRoll ()
	Returns local orientation when it's in hierarchy (Yaw, Pitch, Roll).

proto external vector	GetAngles ()
	Same as GetYawPitchRoll(), but returns rotation vector around X, Y and Z axis.

proto external void	SetAngles (vector angles)
	Same as SetYawPitchRoll(), but sets rotation around X, Y and Z axis.

proto external vector	GetOrigin ()
	Returns origin of Entity.

proto external void	SetOrigin (vector orig)
	Sets origin for entity.

proto external void	SetScale (float scale)

proto external float	GetScale ()

proto external void	GetBounds (out vector mins, out vector maxs)
	Returns local bounding box of model on Entity.

proto external void	GetWorldBounds (out vector mins, out vector maxs)
	Returns quantized world-bound-box of Entity.

proto external volatile void	SendEvent (notnull IEntity actor, EntityEvent e, void extra)
	Dynamic event invocation. Parameters are the same as in `IEntity::EOnXXXX()` methods.

proto external string	GetName ()

proto external int	SetVComponentFlags (VCFlags flags)
	Sets component flags.

proto external void	SetObject (VObject object, string options)
	Sets the visual object to this entity.

proto external EntityFlags	SetFlags (EntityFlags flags, bool recursively=false)
	Sets Entity flags.

proto external EntityFlags	ClearFlags (EntityFlags flags, bool recursively=false)
	Clear Entity flags.

proto external EntityFlags	GetFlags ()
	Returns Entity flags.

proto external EntityEvent	SetEventMask (EntityEvent e)
	Sets event mask.

proto external EntityEvent	ClearEventMask (EntityEvent e)
	Clears event mask.

proto external EntityEvent	GetEventMask ()
	Returns current event mask.

proto external bool	IsLoaded ()

proto external bool	IsRemoved ()

proto external bool	IsDeleted ()

proto external int	Update ()
	Updates entity state/position.

proto external int	AddChild (notnull IEntity child, TNodeId pivot, EAddChildFlags flags=EAddChildFlags.AUTO_TRANSFORM)
	Add Entity to hierarchy. Pivot is pivot index, or -1 for center of parent.

proto external void	RemoveChild (notnull IEntity child, bool keepTransform=false)
	Remove Entity from hierarchy.

proto external void	SetName (string name)

proto external int	SetCameraMask (int mask)
	Sets visibility mask for cameras, where Entity will be rendered.

proto external Physics	GetPhysics ()

proto external Particles	GetParticles ()

proto external Animation	GetAnimation ()

proto external int	Animate (float speed, int loop)
	Updates animation (either xob, or particle, whatever).

proto external int	AnimateEx (float speed, int loop, out vector lin, out vector ang)
	Updates animation (either xob, or particle, whatever).

proto external void	SetBone (TNodeId bone, vector angles, vector trans, float scale)

proto external bool	SetBoneMatrix (TNodeId bone, vector mat[4])

proto external bool	GetBoneMatrix (TNodeId bone, out vector mat[4])

proto external TNodeId	GetBoneIndex (string boneName)

proto external void	GetBoneNames (out notnull array< string > boneNames)

proto external bool	GetBoneLocalMatrix (TNodeId bone, out vector mat[4])

proto external Managed	FindComponent (TypeName typeName)
	Finds first occurance of the coresponding component.

proto external int	FindComponents (TypeName typeName, notnull array< Managed > outComponents)
	Finds all occurances of the coresponding component.

Public Member Functions inherited from Managed
proto external ref Managed	Clone ()
	Return shallow copy of object, or null if it is not allowed (not public constructor)

Protected Member Functions
void	EOnTouch (IEntity owner, IEntity other, int touchTypesMask)
	Event when touched by other entity.

void	EOnInit (IEntity owner)
	Event after entity is allocated and initialized.

void	EOnVisible (IEntity owner, int frameNumber)
	Event when we are visible.

void	EOnFrame (IEntity owner, float timeSlice)
	Event every frame.

void	EOnPostFrame (IEntity owner, float timeSlice)
	Event after physics update.

void	EOnAnimEvent (IEntity owner, int type, int slot)
	Event from animation system.

void	EOnSimulate (IEntity owner, float timeSlice)
	Event before every physics fixed step (can be multiple calls per engine update)

void	EOnPostSimulate (IEntity owner, float timeSlice)
	Event after every physics fixed step (can be multiple calls per engine update)

void	EOnJointBreak (IEntity owner, IEntity other)
	Event when joint attached to RigidBody of this entity is broken.

void	EOnPhysicsMove (IEntity owner)
	Event when physics engine has moved with this Entity.

void	EOnContact (IEntity owner, IEntity other, Contact contact)
	Event when physics engine registered contact with other RigidBody.

void	EOnPhysicsActive (IEntity owner, bool activeState)
	Event when a RigidBody active state is changed between consecutive fixed steps.

void	EOnFixedFrame (IEntity owner, float timeSlice)
	Event every fixed frame.

void	EOnFixedPostFrame (IEntity owner, float timeSlice)
	Event after physics update every fixed frame.

void	EOnUser0 (IEntity other, int extra)
	EntityEvent.EV_USER+0.

void	EOnUser1 (IEntity other, int extra)
	EntityEvent.EV_USER+1.

void	EOnUser2 (IEntity other, int extra)
	EntityEvent.EV_USER+2.

void	EOnUser3 (IEntity other, int extra)
	EntityEvent.EV_USER+3.

void	EOnUser4 (IEntity other, int extra)
	EntityEvent.EV_USER+4.

void	IEntity (IEntitySource src, IEntity parent)
	protected script Constructor

Constructor & Destructor Documentation

◆ IEntity()

void IEntity.IEntity	(	IEntitySource	src,
		IEntity	parent
	)

protected

protected script Constructor

Member Function Documentation

◆ AddChild()

proto external int IEntity.AddChild	(	notnull IEntity	child,
		TNodeId	pivot,
		EAddChildFlags	flags = `EAddChildFlags.AUTO_TRANSFORM`
	)

Add Entity to hierarchy. Pivot is pivot index, or -1 for center of parent.

◆ Animate()

proto external int IEntity.Animate	(	float	speed,
		int	loop
	)

Updates animation (either xob, or particle, whatever).

◆ AnimateEx()

proto external int IEntity.AnimateEx	(	float	speed,
		int	loop,
		out vector	lin,
		out vector	ang
	)

Updates animation (either xob, or particle, whatever).

◆ ClearEventMask()

proto external EntityEvent IEntity.ClearEventMask ( EntityEvent e )

Clears event mask.

Man player = g_Game.GetPlayer();
player.SetEventMask(EntityEvent.VISIBLE );
Print( player.GetEventMask() );
player.ClearEventMask(EntityEvent.ALL );
Print( player.GetEventMask() );

>> 128
>> 0

Parameters

e	event mask

Returns: event mask

◆ ClearFlags()

proto external EntityFlags IEntity.ClearFlags	(	EntityFlags	flags,
		bool	recursively = `false`
	)

Clear Entity flags.

Returns cleared flags.

Man player = g_Game.GetPlayer();
player.ClearFlags(EntityFlags.VISIBLE|EntityFlags.TRACEABLE );
Print( player.GetFlags() );

>> 1610612744

Parameters

flags	Flags to be set
recursively	Flags will be recursively applied to children of hierarchy too

Returns: cleared flags

◆ CoordToLocal()

proto external vector IEntity.CoordToLocal ( vector coord )

Transforms world space position to local space.

Man player = g_Game.GetPlayer();
Print( player.CoordToLocal("500 10 155") );

>> <15254,-54.2004,8745.53>

Parameters

coord world space position to transform

Returns: position in local space

◆ CoordToParent()

proto external vector IEntity.CoordToParent ( vector coord )

Transforms local position to parent(world) space.

Man player = g_Game.GetPlayer();
Print( player.CoordToParent("1 2 3") );

>> <2549,17.6478,2857>

Parameters

coord local position to transform

Returns: position in parent space

◆ EOnAnimEvent()

void IEntity.EOnAnimEvent	(	IEntity	owner,
		int	type,
		int	slot
	)

protected

Event from animation system.

Parameters

owner	The owner entity
type
slot

◆ EOnContact()

void IEntity.EOnContact	(	IEntity	owner,
		IEntity	other,
		Contact	contact
	)

protected

Event when physics engine registered contact with other RigidBody.

Parameters

owner	The owner entity
other	Other Entity who contacted us
contact	Structure describing the contact

◆ EOnFixedFrame()

void IEntity.EOnFixedFrame	(	IEntity	owner,
		float	timeSlice
	)

protected

Event every fixed frame.

Parameters

owner	The owner entity
timeSlice	Fixed time step

Implemented in RplExample3Controller.

◆ EOnFixedPostFrame()

void IEntity.EOnFixedPostFrame	(	IEntity	owner,
		float	timeSlice
	)

protected

Event after physics update every fixed frame.

Parameters

owner	The owner entity
timeSlice	Fixed time step

◆ EOnFrame()

void IEntity.EOnFrame	(	IEntity	owner,
		float	timeSlice
	)

protected

Event every frame.

Parameters

owner	The owner entity
timeSlice	Time passed since last frame

Implemented in AutotestGrid, FPS_Autotest, MotionAutoTest, Screenshot_Autotest, EntityWithRplRpc, RplExampleDebugShape, and RplExample3Controller.

◆ EOnInit()

void IEntity.EOnInit ( IEntity owner )

protected

Event after entity is allocated and initialized.

Parameters

owner The owner entity

Implemented in AutotestGrid, FPS_Autotest, MotionZone, MotionAutoTest, Screenshot_Autotest, CrossroadEntity, and WorldDecal.

◆ EOnJointBreak()

void IEntity.EOnJointBreak	(	IEntity	owner,
		IEntity	other
	)

protected

Event when joint attached to RigidBody of this entity is broken.

Parameters

owner	The owner entity
other	Other Entity attached to the joint

◆ EOnPhysicsActive()

void IEntity.EOnPhysicsActive	(	IEntity	owner,
		bool	activeState
	)

protected

Event when a RigidBody active state is changed between consecutive fixed steps.

Parameters

owner The owner entity

◆ EOnPhysicsMove()

void IEntity.EOnPhysicsMove ( IEntity owner )

protected

Event when physics engine has moved with this Entity.

Parameters

owner The owner entity

◆ EOnPostFrame()

void IEntity.EOnPostFrame	(	IEntity	owner,
		float	timeSlice
	)

protected

Event after physics update.

Parameters

owner	The owner entity
timeSlice	Time passed since last frame

Implemented in ScriptCamera.

◆ EOnPostSimulate()

void IEntity.EOnPostSimulate	(	IEntity	owner,
		float	timeSlice
	)

protected

Event after every physics fixed step (can be multiple calls per engine update)

Parameters

owner	The owner entity
timeSlice	Time slice of physics fixed step

◆ EOnSimulate()

void IEntity.EOnSimulate	(	IEntity	owner,
		float	timeSlice
	)

protected

Event before every physics fixed step (can be multiple calls per engine update)

Parameters

owner	The owner entity
timeSlice	Time slice of physics fixed step

◆ EOnTouch()

void IEntity.EOnTouch	(	IEntity	owner,
		IEntity	other,
		int	touchTypesMask
	)

protected

Event when touched by other entity.

Note: You need to have TouchComponent in entity to receive this event.

Parameters

owner	The owner entity
other	Entity who touched us
touchTypesMask	Bitmask of touch types TODO

◆ EOnUser0()

void IEntity.EOnUser0	(	IEntity	other,
		int	extra
	)

protected

EntityEvent.EV_USER+0.

◆ EOnUser1()

void IEntity.EOnUser1	(	IEntity	other,
		int	extra
	)

protected

EntityEvent.EV_USER+1.

◆ EOnUser2()

void IEntity.EOnUser2	(	IEntity	other,
		int	extra
	)

protected

EntityEvent.EV_USER+2.

◆ EOnUser3()

void IEntity.EOnUser3	(	IEntity	other,
		int	extra
	)

protected

EntityEvent.EV_USER+3.

◆ EOnUser4()

void IEntity.EOnUser4	(	IEntity	other,
		int	extra
	)

protected

EntityEvent.EV_USER+4.

◆ EOnVisible()

void IEntity.EOnVisible	(	IEntity	owner,
		int	frameNumber
	)

protected

Event when we are visible.

Parameters

owner	The owner entity
frameNumber	Frame number

◆ FindComponent()

proto external Managed IEntity.FindComponent ( TypeName typeName )

Finds first occurance of the coresponding component.

Parameters

typeName type of the component

◆ FindComponentData()

proto external EntityComponentPrefabData IEntity.FindComponentData ( TypeName typeName )

◆ FindComponents()

proto external int IEntity.FindComponents	(	TypeName	typeName,
		notnull array< Managed >	outComponents
	)

Finds all occurances of the coresponding component.

Parameters

typeName	type of the component
outComponents	array to fill with selected components

◆ GetAngles()

proto external vector IEntity.GetAngles ( )

Same as GetYawPitchRoll(), but returns rotation vector around X, Y and Z axis.

◆ GetAnimation()

proto external Animation IEntity.GetAnimation ( )

◆ GetBoneIndex()

proto external TNodeId IEntity.GetBoneIndex ( string boneName )

◆ GetBoneLocalMatrix()

proto external bool IEntity.GetBoneLocalMatrix	(	TNodeId	bone,
		out vector	mat[4]
	)

◆ GetBoneMatrix()

proto external bool IEntity.GetBoneMatrix	(	TNodeId	bone,
		out vector	mat[4]
	)

◆ GetBoneNames()

proto external void IEntity.GetBoneNames ( out notnull array< string > boneNames )

◆ GetBounds()

proto external void IEntity.GetBounds	(	out vector	mins,
		out vector	maxs
	)

Returns local bounding box of model on Entity.

Man player = g_Game.GetPlayer();

vector mins, maxs;
player.GetBounds(mins, maxs );

Print( mins );
Print( maxs );

>> <0,0,0>
>> <0,0,0>

Parameters

[out]	mins	minimum point of bounding box
[out]	maxs	maximum point of bounding box

◆ GetChildren()

proto external IEntity IEntity.GetChildren ( )

Returns first child from this level of hierarchy if there is any.

Returns: Pointer to child entity, or nullptr

◆ GetEventMask()

proto external EntityEvent IEntity.GetEventMask ( )

Returns current event mask.

Man player = g_Game.GetPlayer();
Print( player.GetEventMask() );

>> 0

Returns: current event mask

◆ GetFlags()

proto external EntityFlags IEntity.GetFlags ( )

Returns Entity flags.

Man player = g_Game.GetPlayer();
Print( player.GetFlags() );

>> 1610612745

Returns: Entity flags

◆ GetID()

proto external EntityID IEntity.GetID ( )

Return unique entity ID.

ItemBase apple = g_Game.CreateObject( "FruitApple", String2Vector("0 10 0"), false );
Print( apple.GetID() );

>> 0

◆ GetLocalAngles()

proto external vector IEntity.GetLocalAngles ( )

Same as GetLocalYawPitchRoll(), but returns rotation vector around X, Y and Z axis.

◆ GetLocalTransform()

proto external void IEntity.GetLocalTransform ( out vector mat[] )

See IEntity::GetTransform.

◆ GetLocalTransformAxis()

proto external vector IEntity.GetLocalTransformAxis ( int axis )

See IEntity::GetTransformAxis.

◆ GetLocalYawPitchRoll()

proto external vector IEntity.GetLocalYawPitchRoll ( )

Returns local orientation when it's in hierarchy (Yaw, Pitch, Roll).

Man player = g_Game.GetPlayer();
Print( player.GetLocalYawPitchRoll() );

>> <180,-57.2585,180>

Returns: local orientation

◆ GetName()

proto external string IEntity.GetName ( )

◆ GetOrigin()

proto external vector IEntity.GetOrigin ( )

Returns origin of Entity.

Man player = g_Game.GetPlayer();
Print( player.GetOrigin() );

>> <2577.02,15.6837,2924.27>

Returns: entity origin

◆ GetParent()

proto external IEntity IEntity.GetParent ( )

Returns parent of this entity (entity on upper level of hierarchy).

Returns: Pointer to parent entity, or nullptr, when we are not child.

◆ GetParticles()

proto external Particles IEntity.GetParticles ( )

◆ GetPhysics()

proto external Physics IEntity.GetPhysics ( )

◆ GetPivot()

proto external TNodeId IEntity.GetPivot ( )

Returns pivot ID from hierarchy component.

◆ GetPrefabData()

proto external EntityPrefabData IEntity.GetPrefabData ( )

◆ GetRootParent()

proto external IEntity IEntity.GetRootParent ( )

Returns top-parent of this entity.

Returns: Pointer to root entity, or self, when we are not child.

◆ GetScale()

proto external float IEntity.GetScale ( )

◆ GetSibling()

proto external IEntity IEntity.GetSibling ( )

Returns next sibling of this entity (next entity on this level of hierarchy).

Returns: Pointer to sibling entity, or nullptr

◆ GetTransform()

proto external void IEntity.GetTransform ( out vector mat[] )

Returns world transformation of Entity.

It returns only as many vectors as is array length.

Man player = g_Game.GetPlayer();

vector mat[4];
player.GetTransform(mat);
Print( mat );

>> <0.989879,-0,0.141916>,<0,1,0>,<-0.141916,0,0.989879>,<2545.08,15.6754,2867.49>

Parameters

mat	`vector[1...4]` matrix to be get

◆ GetTransformAxis()

proto external vector IEntity.GetTransformAxis ( int axis )

See IEntity::GetTransformAxis.

◆ GetVObject()

proto external VObject IEntity.GetVObject ( )

Returns visual object set to this Entity. No reference is added.

◆ GetWorld()

proto external BaseWorld IEntity.GetWorld ( )

◆ GetWorldBounds()

proto external void IEntity.GetWorldBounds	(	out vector	mins,
		out vector	maxs
	)

Returns quantized world-bound-box of Entity.

Man player = g_Game.GetPlayer();

vector mins, maxs;
player.GetWorldBounds( mins, maxs );

Print( mins );
Print( maxs );

>> <2547.2,15.5478,2852.85>
>> <2548.8,17.5478,2855.05>

Parameters

[out]	mins	minimum point of bounding box
[out]	maxs	maximum point of bounding box

◆ GetWorldTransform()

proto external void IEntity.GetWorldTransform ( out vector mat[] )

See IEntity::GetTransform.

◆ GetWorldTransformAxis()

proto external vector IEntity.GetWorldTransformAxis ( int axis )

See IEntity::GetTransformAxis.

◆ GetYawPitchRoll()

proto external vector IEntity.GetYawPitchRoll ( )

Returns orientation of Entity in world space (Yaw, Pitch, Roll).

Man player = g_Game.GetPlayer();
Print( player.GetYawPitchRoll() );

>> <180,-76.5987,180>

Returns: entity orientation

◆ IsDeleted()

proto external bool IEntity.IsDeleted ( )

Returns: true if entity was deleted (entity pointer valid until the end of the frame).

◆ IsLoaded()

proto external bool IEntity.IsLoaded ( )

Returns: true when entity is loaded from map, false when dynamically spawned.

◆ IsRemoved()

proto external bool IEntity.IsRemoved ( )

Returns: true if entity is ready to be deleted.

◆ RemoveChild()

proto external void IEntity.RemoveChild	(	notnull IEntity	child,
		bool	keepTransform = `false`
	)

Remove Entity from hierarchy.

◆ SendEvent()

proto external volatile void IEntity.SendEvent	(	notnull IEntity	actor,
		EntityEvent	e,
		void	extra
	)

Dynamic event invocation. Parameters are the same as in IEntity::EOnXXXX() methods.

◆ SetAngles()

proto external void IEntity.SetAngles ( vector angles )

Same as SetYawPitchRoll(), but sets rotation around X, Y and Z axis.

◆ SetBone()

proto external void IEntity.SetBone	(	TNodeId	bone,
		vector	angles,
		vector	trans,
		float	scale
	)

◆ SetBoneMatrix()

proto external bool IEntity.SetBoneMatrix	(	TNodeId	bone,
		vector	mat[4]
	)

◆ SetCameraMask()

proto external int IEntity.SetCameraMask ( int mask )

Sets visibility mask for cameras, where Entity will be rendered.

◆ SetEventMask()

proto external EntityEvent IEntity.SetEventMask ( EntityEvent e )

Sets event mask.

Man player = g_Game.GetPlayer();
Print( player.GetEventMask() );
player.SetEventMask( EntityEvent.VISIBLE );
Print( player.GetEventMask() );

>> 0
>> 128

Parameters

e	Combined mask of one or more members of EntityEvent enum

◆ SetFixedLOD()

proto external void IEntity.SetFixedLOD ( int lod )

Set fixed LOD. Use -1 for non-fixed LOD.

◆ SetFlags()

proto external EntityFlags IEntity.SetFlags	(	EntityFlags	flags,
		bool	recursively = `false`
	)

Sets Entity flags.

It's OR operation, not rewrite. Returns previous flags.

Man player = g_Game.GetPlayer();
player.SetFlags(EntityFlags.VISIBLE|EntityFlags.TRACEABLE );
Print( player.GetFlags() );

>> 1610612747

Parameters

flags	Flags to be set
recursively	Flags will be recursively applied to children of hierarchy too

Returns: previous flags

◆ SetLocalTransform()

proto external bool IEntity.SetLocalTransform ( vector mat[4] )

See IEntity::SetTransform. Returns false, if there is no change in transformation.

◆ SetName()

proto external void IEntity.SetName ( string name )

◆ SetObject()

proto external void IEntity.SetObject	(	VObject	object,
		string	options
	)

Sets the visual object to this entity.

Reference is added and released upon entity destruction.

Parameters

object	Handle to object got by GetObject().
options	String, dependent on object type. The only one supported for XOB objects: `"$remap 'original material name' 'new material'; [$remap 'another original material name' 'another new material']"`

◆ SetOrigin()

proto external void IEntity.SetOrigin ( vector orig )

Sets origin for entity.

Man player = g_Game.GetPlayer();
player.SetOrigin("2550 10 2900" );
Print( player.GetOrigin() );

>> <2550,10,2900>

Parameters

orig	origin to be set

◆ SetScale()

proto external void IEntity.SetScale ( float scale )

◆ SetTransform()

proto external bool IEntity.SetTransform ( vector mat[4] )

Sets entity world transformation.

vector mat[4];
Math3D.MatrixIdentity( mat )

Man player = g_Game.GetPlayer();
player.SetTransform( mat );

vector outmat[4];
player.GetTransform(outmat );
Print( outmat );

>> <1,0,0>,<0,1,0>,<0,0,1>,<0,0,0>

Parameters

mat	matrix to be set

◆ SetVComponentFlags()

proto external int IEntity.SetVComponentFlags ( VCFlags flags )

Sets component flags.

◆ SetWorldTransform()

proto external bool IEntity.SetWorldTransform ( vector mat[4] )

See IEntity::SetTransform. Returns false, if there is no change in transformation.

◆ SetYawPitchRoll()

proto external void IEntity.SetYawPitchRoll ( vector angles )

Sets angles for entity (Yaw, Pitch, Roll).

Man player = g_Game.GetPlayer();
player.SetYawPitchRoll("180 50 180" );
Print( player.GetYawPitchRoll() );

>> <-180,50,-180>

Parameters

angles angles to be set

◆ Update()

proto external int IEntity.Update ( )

Updates entity state/position.

Should be called when you want to manually commit position changes etc before trace methods etc. Entity is updated automatically at the end and the beginning of simulation step, when it has EntityFlags.TFL_ACTIVE flag set.

Returns

Mask with flags:

EntityFlags.UPDATE - hierarchy has been updated
EntityFlags.UPDATE_MDL - model hierarchy has been updated

◆ VectorToLocal()

proto external vector IEntity.VectorToLocal ( vector vec )

Transforms world space vector to local space.

Man player = g_Game.GetPlayer();
Print( player.VectorToLocal("2 1 5") );

>> <-0.166849,1,5.38258>

Parameters

vec	world space vector to transform

Returns: local space vector

◆ VectorToParent()

proto external vector IEntity.VectorToParent ( vector vec )

Transforms local vector to parent(world) space.

Man player = g_Game.GetPlayer();
Print( player.VectorToParent("1 2 3") );

>> <2.89791,2,1.26575>

Parameters

vec	local space vector to transform

Returns: parent space vector

The documentation for this interface was generated from the following file:

Core/generated/Entities/IEntity.c

Public Member Functions

Protected Member Functions

Constructor & Destructor Documentation

◆ IEntity()

Member Function Documentation

◆ AddChild()

◆ Animate()

◆ AnimateEx()

◆ ClearEventMask()

◆ ClearFlags()

◆ CoordToLocal()

◆ CoordToParent()

◆ EOnAnimEvent()

◆ EOnContact()

◆ EOnFixedFrame()

◆ EOnFixedPostFrame()

◆ EOnFrame()

◆ EOnInit()

◆ EOnJointBreak()

◆ EOnPhysicsActive()

◆ EOnPhysicsMove()

◆ EOnPostFrame()

◆ EOnPostSimulate()

◆ EOnSimulate()

◆ EOnTouch()

◆ EOnUser0()

◆ EOnUser1()

◆ EOnUser2()

◆ EOnUser3()

◆ EOnUser4()

◆ EOnVisible()

◆ FindComponent()

◆ FindComponentData()

◆ FindComponents()

◆ GetAngles()

◆ GetAnimation()

◆ GetBoneIndex()

◆ GetBoneLocalMatrix()

◆ GetBoneMatrix()

◆ GetBoneNames()

◆ GetBounds()

◆ GetChildren()

◆ GetEventMask()

◆ GetFlags()

◆ GetID()

◆ GetLocalAngles()

◆ GetLocalTransform()

◆ GetLocalTransformAxis()

◆ GetLocalYawPitchRoll()

◆ GetName()

◆ GetOrigin()

◆ GetParent()

◆ GetParticles()

◆ GetPhysics()

◆ GetPivot()

◆ GetPrefabData()

◆ GetRootParent()

◆ GetScale()

◆ GetSibling()

◆ GetTransform()

◆ GetTransformAxis()

◆ GetVObject()

◆ GetWorld()

◆ GetWorldBounds()

◆ GetWorldTransform()

◆ GetWorldTransformAxis()

◆ GetYawPitchRoll()

◆ IsDeleted()

◆ IsLoaded()

◆ IsRemoved()

◆ RemoveChild()

◆ SendEvent()

◆ SetAngles()

◆ SetBone()

◆ SetBoneMatrix()

◆ SetCameraMask()

◆ SetEventMask()

◆ SetFixedLOD()

◆ SetFlags()

◆ SetLocalTransform()
